National Technology General MCU N32G430

High performance: The chip is equipped with a 32-bit Arm® Cortex®-M4F core, clocked at 128MHz, supports floating point operations and DSP instructions, and integrates up to 64KB embedded encrypted Flash and 16KB SRAM. It has the best performance under the same resource configuration, reaching 160 DMIPS, CoreMark score 420, and standby power consumption as low as 3uA (3.3V/25℃).

High reliability: More robust IO ports, stronger ESD capabilities, high-precision and highly reliable clock systems, and a wide ambient temperature range of -40~105°C enhance the advantages of industrial-grade high reliability.

High integration: built-in 1 12bit 4.7Msps ADC, 3 high-speed comparators, integrated multi-channel communication interface. The ADC performance is industry-leading, with 4.7Msps-10Msps high-speed sampling capability.

Small size: 7 product packages are provided, among which UQFN20 (3mmx3mm) is the smallest and most powerful product in the industry.

Hardware-level security: Uses chip-level security technologies such as Flash storage encryption, multi-user partition management, write protection (WRP), multiple read protection (RDP) levels (L0/L1/L2), and encrypted downloads to protect users’ intellectual property rights.
