Nations Technologies Low Power Bluetooth Chip N32WB031

The N32WB031 series is a new generation of high-performance, ultra-low-power Bluetooth 5.1 chips from National Technology. Integrated advanced BLE5.1 radio frequency transceiver, compliant with Bluetooth BLE5.1 specification, can be configured as standard 1Mbps BLE mode, 2Mbps enhanced BLE mode, 125kbps BLE remote mode (S8), 500kbps BLE remote mode (S2).

Quick inquiry

Congratulations, the submission was successful. Please be patient and wait for us to contact you.

Back

Product quantity

Home > Manufacturer > NationsTech > product details

Merchant qualification:

National Technology Co., Ltd. was established in 2000 due to the national &quot;909&quot; integrated circuit special project. It was listed on the GEM in 2010. It is a leading enterprise in general MCUs and security chips and a national high-tech enterprise.

Product Introduction&Application Fields

product details

Ultra-low power consumption: transmitting current 2mA, receiving current 3.8mA. Sleep (64KB RAM retention): 1.4μA; PD mode: 130nA; chip power consumption is only 2.9μA when automatically scanning 104 keys; average power consumption at 1 second broadcast interval is 12μA.

Efficient protocol stack: supports the full-featured Bluetooth® LE 5.1 protocol, the protocol stack is located in ROM and does not occupy FLASH space; supports master/slave multi-connection, supports SIG Mesh, 1Mbps air interface rate, and 80KB/S high-speed data transmission rate.

High-standard radio frequency: maximum transmit power +6dBm, receiving sensitivity -96dBm @BLE 1Mbps.

High integration: The chip has rich internal resources and peripheral interfaces, greatly reducing customer costs.
