Neoway N75 wireless communication module

N75 is an LTE Cat.4 module optimized for M2M and IoT applications. It uses 3GPP Rel.11 LTE technology and provides 150 Mbps downlink and 50 Mbps uplink data rates. N75 supports positioning suite Gen8C Lite (GPS, GLONASS, BDS, Galileo, QZSS). The integrated GNSS greatly simplifies product design and provides faster, more accurate and more reliable positioning. Ultra-low power consumption, ultra-wide operating temperature, excellent RF performance, rich network protocols, industry-standard interfaces and ultra-high performance (USB serial driver for Windows 7/8/8.1/10, Linux, Android), This makes N75 suitable for industry applications such as energy metering, Internet of Vehicles, industrial routing, security products, and environmental monitoring.

Quick inquiry

Congratulations, the submission was successful. Please be patient and wait for us to contact you.

Back

  • Product quantity

Home > Manufacturer > Neoway Technology > product details

Merchant qualification:

Shenzhen Neoway Technology Co., Ltd. focuses on the connection of the Internet of Things and focuses on providing Internet of Things access communication products and services to Internet of Things service providers and intelligent Internet product manufacturers.

Product Introduction&Application Fields

product details

  • Operating voltage: 3 V~4.3 V, TYP.: 3.8 V

  • Dimensions: 30.0 mm × 28.0 mm × 2.8 mm

  • Package: 100-pin LGA

  • Open development: optional (ROM: 2 Gb or 1 Gb; RAM: 1 Gb)

  • Interface: PCM/I2S; ADC x 2; I2C x 1 (Open); SPI x 1 (Open); UART x 2; USB 2.0; PWRKEY_N; RESET_N; DTR (low power control); NET_LIGHT; USIM (1.8 V/ 3.0 V); SGMII (Open); SDIO 3.0 (Open); SD card (Open)

  • GNSS: GPS/BDS/GLONASS

  • Frequency Band: China: LTE FDD: B1/B3/B5/B8; LTE TDD: B38/B39/B40/B41; TD-SCDMA: B34/B39; UMTS: B1/B8; CDMA2000 1X/EV-DO: BC0; GPRS |EDGE: 900/1800 MHz; Europe: LTE FDD: B1/B3/B5/B7/B8/B20; LTE TDD: B40; UMTS: B1/B8; GSM|GPRS|EDGE: 900/1800 MHz; Middle East: LTE FDD: B1/B3/B8/B20/B28; LTE TDD: B38/B40/B41; UMTS: B1/B8; GSM|GPRS|EDGE: 900/1800 MHz

  • Protocol: TCP/UDP/TLS/MQTT/DNS/FTP/HTTP/HTTPS/NTP/NITZ

  • ESD performance: VBAT: ±8 kV/±15 kV; GND: ±8 kV/±15 kV; ANT: ±8 kV/±15 kV; Others: ±4 kV/±8 kV

Product specifications
