Geehy MCU automotive grade APM32A407

APM32A407 series of automotive-grade MCUs, based on the Arm® Cortex®-M4 core, takes into account the characteristics of high computing, high real-time and ease of use. It has excellent CPU computing performance and supports single-precision FPU and enhanced DSP processing instructions; large storage The space can meet the data computing needs of complex programs, and the peripheral resources are abundant to meet the needs of multiple applications. It supports the high-speed OTG interface of the on-chip PHY; it has passed AEC-Q100 automotive certification, complies with automotive grade reliability test standards, and the operating temperature covers -40 ℃~+125℃, can be used in vehicle navigation, charging piles, vehicle instruments, Tbox, car lights and other fields.

Quick inquiry

Congratulations, the submission was successful. Please be patient and wait for us to contact you.

Back

  • Product quantity

Home > Manufacturer > Geehy > product details

Merchant qualification:

Zhuhai Geehy Semiconductor Co., Ltd. is an integrated circuit design company dedicated to the development of industrial-grade/automotive-grade microcontrollers, high-performance analog chips and system-level chips. Its headquarters is Ninestar Co., Ltd.

Product Introduction&Application Fields

product details

  • System: Arm® Cortex®-M4 core, working frequency 168MHz

  • Storage: Flash 1024KB, SRAM 192+4KB

  • Timers: 16-bit/32-bit general-purpose timer: 8/2; 16-bit basic timer: 2; 16-bit advanced timer: 2; watchdog timer: 2; system timer: 1

  • Analog peripherals: 12-bit ADC: 3, number of channels: 16/24; 12-bit DAC: 2, number of channels: 2

  • I/Os: 82/114 I/Os, all can be mapped to external interrupt vectors

  • Debug mode: SWD, JTAG

  • Peripheral resources: U(S)ART: 4+2; I2C: 3; SPI/I2S: 3/2; CAN: 2; USB OTG: 3; SDIO: 1, DCI: 1; Ethernet: 1

  • Vehicle regulations: AEC-Q100 Grade1/Grade2, operating temperature coverage -40℃~125℃

  • Security: BN/SM3/SM4

  • Package: LQFP100/144
